ComPacT NS630-3200 circuit breakers are equipped with a MicroLogic trip unit designed to help protect power circuits and connected loads.
X : Type of protection
-
2 for basic protection
-
5 for selective selection
-
6 for selective + ground-fault protection
-
7 for selective + earth-leakage protection
Y : Version number
Identification of the trip unit generation (0 is the first generation.)
Z : Type of measurement
-
A : Ammeter
-
E : Energy meter
-
P : Power meter
-
No indication : No measurements
Range of MicroLogic A/E Trip Units
The following table indicates the standard functions available on ComPacT NS circuit breakers with MicroLogic A/E trip units:
|
Function |
MicroLogic trip unit | ||||||
|---|---|---|---|---|---|---|---|
| 2.0 A | 2.0 E | 5.0 A | 5.0 E | 6.0 A | 6.0 E | 7.0 A | |
|
Long-time overcurrent protection (L) |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Short-time overcurrent protection (S) |
– |
– |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Instantaneous overcurrent protection (I) |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Ground-fault protection (G) |
– |
– |
– |
– |
✔ |
✔ |
– |
|
Earth-leakage protection (E) |
– |
– |
– |
– |
– |
– |
✔ |
|
Neutral protection on 4P circuit breaker |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Overload LED |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
|
Trip cause indicators |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
